The Baykal BLS Pro Series redefines the boundaries of CNC laser cutting machine with its expansive model range and powerful high-precision options.
Discover the full potential of Baykal's latest laser technology for your operation by accessing our comprehensive brochure and product guide.
An industrial CNC laser cutter, the BLS Pro series combines superior IPG YLS fibre laser sources with advanced features, such as the Precitec ProCutter auto-focus head and Beckhoff servo motors, for unmatched cut quality and performance.
Enhanced with an intuitive touchscreen controller, automatic edge detection, and nozzle maintenance, this specialised CNC fibre laser cutting machine sets the industry standard for efficiency and operator-friendly laser cutting technology.
Baykal's BLS Pro series introduces a versatile lineup of fibre laser machines, including the compact BLS Pro 4020, the larger BLS Pro 6020, and the highly customisable BLS ProCUSTOM option. This diversity perfectly matches every production scale, from small, bespoke workshops to large-scale manufacturing environments.
The BLS Pro features power settings ranging from 6kW to 20kW, designed to cater to a wide variety of cutting needs. Whether you require the utmost precision for intricate designs or need to meet high-volume production demands, the series' extensive power spectrum offers outstanding flexibility.
This adaptability makes the BLS Pro models ideal for businesses with detailed precision work and large-scale production runs, providing them with the tools they need to excel in their respective markets.
Outfitted with superior IPG YLS fibre laser sources, the BLS Pro promises outstanding cut quality and assures the machinery's longevity and dependability.
Incorporating features like the globally acclaimed Precitec ProCutter head, with auto-focus capability, alongside the Beckhoff high-torque servo motors, the BLS Pro is engineered for peak performance.
To further enhance the user experience, the series includes an intuitive touchscreen controller that significantly simplifies the programming process, making it more accessible and less time-consuming for operators.
These operator-friendly features not only streamline the cutting process but also contribute to minimising downtime, thereby optimising productivity and operational efficiency.
The BLS Pro is designed for high operational throughput and safety, including a protective viewing window, light guards and magnetic locking.
Options like bevel cutting, enhanced software, parts conveyor and fume extraction systems allow workshops to customise their BLS Pro laser cutting machine to their specific needs, improving utility and safety.
With Performatec you can rely on unmatched expertise to guide your decisions with pinpoint accuracy. Your advancement is our commitment. Reach out to us now.
The BLS Pro series is equipped to deliver precision cutting across a wide range of power options, from 6kW to 20kW. Merging an advanced IPG YLS source with user-centric Beckhoff controls and safety-focused design, the BLS Pro series stands ready to elevate your operational capacity and ensure the safety of your workforce.
NOTE: There are significant differences between the BLE-Pro and the BLS-Pro models. To make it easier to distinguish, please click the link for our Laser cutters comparison chart.
| Series: | BLS Pro | ||||||||||||||||||||||||
| Work Envelope: | 2000 X 4000 mm | 2000 X 6000 mm (up to 3000 X 15000 mm) | ||||||||||||||||||||||||
| CNC Control Unit: | Beckhoff CNC (18.5 "TFT-Windows 10) | ||||||||||||||||||||||||
| Motors / Drivers: | Rack and Pinion | Beckhoff (Rotary Servo) | Linear Motion | Beckhoff (Linear Servo) | Motion System | Wittenstein | Bosch Rexroth | Rapid Traverse | 115 m/min | 150 m/min | Vector Speed | 165 m /min | 215 m/min | Acceleration | 2.2G (22m/s2) | 3.0 G (30m/s2) | Abs. Pos. Accuracy | ± 0.02 mm | ± 0.01 mm | Repeatability | ± 0.02 mm | ± 0.01 mm | Feed Rate | Up to 100 m/min | Up to 125 m/min |
| Transfer Table: | Motorised - Automatic Exchange | ||||||||||||||||||||||||
| NOZZLE CLEAN/CALIB. | Automatic | ||||||||||||||||||||||||
| FUME EXt. / BEVEL CUTting HEAD: | Optional |
| Laser Power: | 6 kW to 20kW |
| Cutting Head (Standard): | Precitec ProCutter |
| Cutting Head (Optional): | Precitec ProCutter |
| Focusing Lenses: | 150 mm |
| Material: | 6 kW | 8 kW | 10 kW | 12 kW | 15 kW | 20 kW |
| Mild Steel: | 25 | 25 | 30 | 35 | 35 | 40 |
| stainless Steel: | 25 | 25 | 30 | 35 | 35 | 40 |
| Aluminium: | 25 | 25 | 30 | 35 | 35 | 35 |
| Copper: | 12 | 12 | 16 | 20 | 20 | 20 |
| Brass: | 16 | 16 | 16 | 20 | 20 | 25 |
The Baykal BLS PRO Series is expertly engineered to cater to the demanding needs of contemporary production environments. It adeptly processes a wide range of materials, from stainless steel to aluminium, demonstrating its outstanding versatility.
Its advanced construction and state-of-the-art features position it as a critical asset for any production setting, ensuring peak productivity within a minimal footprint.
The BLS Pro series offers precision, exceptional quality and reliability. Bringing enhanced versatility with focus adjustment for a superior cutting experience across 6kW to 20kW, the world-leading Precitec ProCutter offers maximum productivity thanks to its superior technology, and provides consistent, around-the-clock cut quality even at high power.
Maximise efficiency with LANTEK's advanced nesting software. This platform optimises material utilisation, minimises waste, and streamlines operations. The software ensures each cut is precise, reducing material loss and improving overall workflow.
Maintain vigilance and production control over your cutting operations with the optional integrated camera system. This feature allows real-time monitoring for operational safety, enabling immediate adjustments and ensuring precision and quality.
The BLS Pro series has a leading-edge Beckhoff CNC controller, offering an intuitive user interface for unparalleled precision and operational speed. This central control system simplifies complex tasks, ensuring seamless operation and consistently high-quality outputs.
The BLS Pro series ensures a pristine working environment with an optional fume extractor. This system effectively removes airborne particles and fumes generated during cutting, safeguarding air quality and operator health while maintaining regulatory compliance.
Enhance your BLS Pro laser with Baykal's optional automatic nozzle changer for streamlined operations. This innovative system swiftly adjusts nozzles to match cutting specifications, reducing manual workload and keeping your workflow uninterrupted.
Baykal's BLS Pro has an optional built-in automated nozzle cleaning and calibration feature to help keep your laser in peak condition. This ensures continuous operation, minimises potential downtime, and prolongs the lifespan of your laser-cutting equipment.
The BLS Pro series prioritises operator and machine safety with features like the magnetic safety lock, which secures the laser cutting area during operation. This system prevents unauthorised access, ensuring a safe working environment for operators and protection for your equipment.
To find out, download the 2025 Fibre Laser Buyer’s Guide, a side-by-side comparison of Baykal’s BLE, BLS series machines, with indicative pricing by bed size, laser power, motion system, and automation level.
What's inside:
Performatec supplies high-performance fibre laser cutters built for precision, speed and low operating costs.
With over 20 years of CNC experience, we support Australian manufacturers with expert advice, local install, and service that actually shows up. From job shops to heavy fabrication, we help you choose the right machine and keep it cutting.
